CONICAL SPRING SEALS
Series FMS201
Series FMS201 is single conical spring, unbalanced seal with O-ring provided for secondary sealing. Since the Torque transmission is done by the single coil springs the seals are dependent on the directions of rotation, which is seen from the drive end of the shaft. Right handed spring and left handed springs are provided for clockwise and anticlockwise rotating shafts respectively. These seals can carry a variety of seals faces, serving applications in submersible, sewage, chemical transfer, water pumps etc.
Applications
• Water pumpsPerformance Range
• Shaft Diameter : 10-100mm• Pressure : 10 bar (max)
• Temperature : -20...180OC
• Velocity : 10 m/sec
Materials
• Seal Faces : Carbon, Ceramic, SiC, Tung. Carbide• Metal Parts : SS304, SS316
• O-rings : Elastomers, TTV
